주거용, 상업시설, 오피스용내 소방구역내 스프링 쿨러 연결배관에 사용되는 화재진압용 소방용 밸브, 버터 플라이, 체크 밸브로서, 배관연결 부분 명칭에 따라 Groove타입, Flange타입이 있으며, 인디케이터, 기어박스, 밸브바디, 디스크로 구성 되어 있습니다. 밸브 바디속에 디스크에 의해 수량이 제외되며, 개폐가 용이하며 무거가 가벼우며, 기어박스는 방수(IP65)기능을 가지고 있다. 플랜드 타입 및 커플링 조인트 타입 배관과 연결 가능합니다.
This butterfly valve is generally used for installing sprinkler line in residential or commercial construction. it has grooved inlet and outlet connections that are suitable for use with grooved end pipe couplings that are listed and approved for fire protection systems.
1. Body: Groove Type
2. Working Pressure: 300psi (21bar)
3. Max. Test Pressure: 600psi(42bar)
4. Temperature Range : ~250F(~120℃)
5. Gearbox: IP65, bronze travelling nut gearbox with internal dual switch in ductile iron housing. Indor / Out door
